新店裝璜 燈光設計



1.  全系列  戶內外  LOGO  投射燈

2.  室內外  氣氛浪漫   圖案投射燈

3.  戶內外   創意廣告  圖案投射燈

 4.  戶內外  光學 HID    圖案投影燈

 5.  高功率  多功能性   圖案投影燈

 6.  雷射燈   編寫圖文  雷射燈系列

 7.  雪花 煙霧機  泡泡機  轟叭燈

  8.  L E D搖頭燈 舞台燈光搖頭系列
  9.  客服信箱 E-mail信箱 電話咨詢



統大企業有限公司提供專業的、投射燈系列、廣告投射燈、廣告招牌、廣告行銷、廣告燈具、效果燈、投影燈、PAR燈、
摇頭燈、電腦燈、追蹤燈、GOBO、客製化GOBO圖案片、電腦燈圖案片 、LED燈飾、LED發光字、LED跑馬燈、大圖輸出
燈箱、布旗、布條、各類廣告資材等並提供婚禮客製化GOBO、室內設計、 展場、展示會、歐美特殊燈泡及進口燈具。


New LOGO Projector

Interior Lighting



Possible settings








Function

635W LOGO Projector is a compact, powerful projection light for indoor. With compact size and low power consumption, this projector can be use in many different scene. 32W HID Lamp combined stabilizer, high color rendering, image rotation type projector with zoom lens. Strongly recommend for its strong beam power.

Shops (on walls, floors, shop windows or pavements), trade fairs and shows, department stores and showrooms.
Service and tourist industry:
Banks, restaurants, fast food outlets, hotels, bars, coffee & tea houses, tourist agencies, airports and stations.
Recreation ground:
Sports halls, gyms, bowling-alleys, amusement arcades, nightclubs, art galleries and museums.
Other activities:
Conferences, industrial presentations, theaters, cinemas, weddings, contract advertising, coffee shop, department stores. It is suitable for the restaurant and places like karaoke, the club disco, and the lounge bar, etc. It is very compact and low power consumption. It can also be use in places which is silence and romantic like concert, western restaurant, exhibition, art gallery etc.

Handily by the button operation that is easy to operate. Low power consumption, 32W HID Lamp combined stabilizer, high color rendering, image rotation type projector with zoom lens. You can control the project image size by adjusting the projector distance. Make the image rotate by pressing the button, and the gobo can be exchange easily.

Gobo
GOBO Size: outer diameter = φ37.3mm/ image size = φ20.0mm
Model No.    635H  LOGO Projector

Interior Design

Power consumption       70W
Color temperature      3000k  white color
Lamp       32W HID Lamp
Average lamp longevity     3000 hrs

Lamp amount

     1 pc
Gobo Rotational speed

     2 - 2.5 R.P.M  360°Image rotation type

(Gobo is custom-made)

Voltage   100V〜220V ~   240V   /    50 ~ 60Hz
Zoom distance
DMX

   FPC zoom manual control, button operation which is easy to operate, don't have to use DMX.

Size   LxWxH       250 × 80 × 200 mm

Weight
   1.8kg   ( with stabilizer in projector)
With an interchangeable pattern disk (gobo) you can adjust your message to whatever the occasion – clubs, birthdays, bar mitzvahs or weddings.Color filters can also be added and as with all Mania products, there is no duty cycle so it can run all night!

燈光效果對於商店來說,店面氛圍非常依靠燈光效果,亦是吸引顧客的必不可少的條件,如果設計規模上忽視燈光效果或是為省電而將點綴燈光關閉,店家業者肯定會得不償失。
Tong-Da Industry Co. products LOGO Projector, interior light, glass gobo and metal gobo are all manufactured and assembled in Taiwan. Our company is the direct sale of export and mail order to overseas.
